TE Connectivity TRAB4500N - 450-470 Phantom Antenna
Slide 1 of 1
Manufacturer
TE Connectivity
MPN
TRAB4500N
Available
0
Condition
New
LAIRD 450-470MHz Phantom 3dB low profile Black antenna. No Ground Plane. Order Motorola style mount & cable separately.
The TE Connectivity TRAB4500N is a high-performance Phantom Antenna designed for use in the frequency range of 450-470 MHz. It is designed to provide excellent coverage and signal strength in the 450-470 MHz frequency range, making it ideal for use in both urban and rural areas. This antenna features a low-profile design, making it virtually invisible when mounted on a vehicle or building. The TRAB4500N is a Phantom Antenna, which means it does not require a ground plane for installation. With its high gain and low VSWR (Voltage Standing Wave Ratio), the TRAB4500N provides excellent signal reception and transmission, ensuring clear and reliable communication.
| Frequency Group | UHF (300MHz ~ 1GHz) | |
| Frequency (Center/Band) | 460MHz | |
| Frequency Range | 450MHz ~ 470MHz | |
| Antenna Type | Dome | |
| Number of Bands | 1 | |
| VSWR | 2 | |
| Return Loss | - | |
| Gain | 3dBi | |
| Power - Max | 100 W | |
| Features | - | |
| Termination | NMO | |
| Ingress Protection | - | |
| Mounting Type | Base Mount | |
| Height (Max) | 3.400" (86.36mm) |
