Manufacturer
Nortel
MPN
NTK583AAE6
Available
2
Condition
New
Interface, Module, Multirate 1528.38-1568.77 50
The Nortel NTK583AAE6 is an interface module designed for use with the Multirate 1528.38-1568.77 50 platform. It is specifically designed to provide high-speed connectivity and advanced features for the Multirate 1528.38-1568.77 50 platform. With this interface module, users can expect reliable and efficient performance for their network needs.
Specifications | |
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | Tunable 50GHz Step |
| RX Wavelength: | ITU-T DWDM Grid 50 GHz C-Band, ITU-T DWDM Grid 100 GHz C-Band |
| Minimum Optical Budget: | 22 dB |
| Maximum Distance: | 80km |
| Supported Data Rate: | 8.5-11.32 Gbps |
| Supported Applications: | 10G Ethernet (10.31Gbps), 10G Fiber Channel (10.52 Gbps), 8G Fiber Channel (8.5 Gbps), STM-64 (9.95Gbps), ODU2 (10.037Gbps), ODU2e (10.399Gbps), OTU2 (10.70Gbps), OTU1f (11.27Gbps), OTU2f (11.32Gbps), OTU1e (11.049Gbps), OTU2e (11.095Gps) |
| DDM/DOM: | Support |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | ITU 50Ghz Grid: C-Band (Ch17-61) |
| Rx Wavelength Bandwidth: | 1260 – 1620 nm |
| Minimum Transmitting Power: | -1 dB |
| Maximum Transmitting Power: | 3 dB |
| Receiver Sensitivity: | -23 dBm |
| Receiver Overload: | -8 dBm |
| Dispersion: | 1600 ps/nm |
| Transmitter Type: | Monolithic MZM Tunable TOSA |
| Receiver Type: | APD Photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Compliance: | CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8077i XFP MSA Rev.4.5, RoHS |
| Transceiver Type: | XFP |
