MikroTik RBD23UGS-5HPacD2HnD-NM – Wireless AP – Dual-Band – SFP
Slide 1 of 4
Manufacturer
Mikrotik
MPN
RBD23UGS-5HPacD2HnD-NM
Available
0
Condition
New
MikroTik RBD23UGS-5HPacD2HnD-NM – Wireless AP – Dual-Band – SFP
The MikroTik RBD23UGS-5HPacD2HnD-NM is a high-performance wireless access point that offers dual-band connectivity and SFP support. It is designed for use in small to medium-sized networks, providing reliable and fast wireless coverage.
It also has a built-in 5-port Gigabit Ethernet switch, providing fast and reliable wired connections for devices such as computers, printers, and smart TVs. One of the standout features of this access point is its SFP support, which allows for the use of fiber optic cables for long-distance connections.
Specifications | |
| Architecture | ARM 32bit |
| CPU | IPQ-4019 |
| CPU core count | 4 |
| CPU nominal frequency | 716 MHz |
| CPU Threads count | 4 |
| Switch chip model | IPQ-4019 |
| Dimensions | 143 x 247 x 48 mm |
| RouterOS license | 4 |
| Operating System | RouterOS |
| Size of RAM | 256 MB |
| Storage size | 16 MB |
| Storage type | FLASH |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -40°C to 70°C |
Powering | |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 12-57 V |
| Max power consumption | 28 W |
| Max power consumption without attachments | 12 W |
| PoE in | 802.3af/at |
| Cooling type | Passive |
| PoE in input Voltage | 24-57 V |
Wireless specifications | |
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
| Wireless 2.4 GHz Number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Wireless 2.4 GHz chip model | IPQ-4019 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
| Wireless 5 GHz Max data rate | 867 Mbit/s |
| Wireless 5 GHz Number of chains | 2 |
| Wireless 5 GHz standards | 802.11a/n/ac |
| Wireless 5 GHz chip model | IPQ-4019 |
| Wireless 5 GHz generation | Wi-Fi 5 |
Ethernet | |
| 10/100/1000 Ethernet ports | 1 |
Fiber | |
| SFP ports | 1 |
Peripherals | |
| Number of SIM slots | 1 Modem (Micro SIM) |
| MiniPCI-e slots | 1 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1 |
Please refer to the following attachments for additional details on the product.
No specifications available.
