Manufacturer
Ericsson
MPN
SLP10K1F
Available
54
Condition
New
Ericsson SLP10K1F - Surge Protection Device
The Ericsson SLP10K1F is a high-quality surge protection device designed to protect your electronic devices from power surges and spikes. It is equipped with advanced surge protection technology that can detect and divert excess voltage away from your devices, ensuring their safety and longevity. It features multiple outlets, allowing you to connect multiple devices and protect them all at once.
Single stage protection with primary or combination primary/secondary protectors
10 pair protector
Simple installation into Krone LSA disconnect block
Data Line Terminator (DLT) available where screw terminal connections are required
SPECIFICATIONS | |
| Max Continuous Operating Voltage (Uc) | 190 VDC |
| Max Discharge Current (Imax), L+L-PE | 20 kA 8/20 μs |
| Rated Load Current (IL) | 1,000 mA |
| Frequency | 12 MHz Max |
| Transmission Rate | 8 Mb/s |
| Protection Modes | L-L |
| Technology | Single-stage |
| Connection Type | Krone® LSA-PLUS |
| Impedance Balance | 48 dB Max |
| Insertion Loss | .75 Db Max |
| Return Loss | 22 dB Max |
| Loop Resistance | 0.2 Ω |
| Temperature | -20 to 60 °C |
| Enclosure Material | UL® 94V-0 Thermoplastic |
| Depth (D) | 21 mm |
| Height (H) | 35 mm |
| Width (W) | 125 mm |
| Unit Weight | 0.02 kg |
Please refer to the following attachments for additional details on the product.
