Manufacturer
Electro Wire Incorporated
MPN
58868501
MOQ
137
Available
0
Condition
New
14G L2 Black
Introducing the Electro Wire Incorporated 58868501 - 14g L2 Black, the perfect solution for all your electrical wiring needs. The 58868501 wire is made with 14-gauge thickness, making it suitable for a wide range of applications. This wire is made with top-grade materials to ensure maximum conductivity and durability.
ASTM B33 Standard Specification for Tin-Coated Soft or Annealed Copper Wire
ASTM B172 Standard Specification for Rope-Lay-Stranded Copper Conductors Having Bunch-Stranded Copper Conductors
UL 44 Type RHH, FT4-ST1, VW-1, 600 Volts DC or AC
UL 2731 Telecommunications Central Office Power Cable
CSA AWM IB 105°C 600V. FT4-ST1
IEC including 60674 and 60332
RoHS Compliant Lead-Free, Silicone-Free
KS-24194 List 2
ATIS-0600017.2014 Non-Halogenated DC Power Wire and Cable for Telecommunications Power Systems
Telcordia GR-347-CORE
REACH - European Community Regulation
| Size (AWG or kcmil) | 14 AWG | |
| No. of Strands | 41 | |
| Nominal Total Weight (lbs/1000') | 27 | lbs/1000' |
| Allowable Ampacity at 75C | 20 | |
| Allowable Ampacity at 90C | 25 | |
| Insulation Thickness (mils) | 45 | mils |
| DC Resistance at 25°C | 2.73 | |
| Temperature Rating (Max) | 105°C | |
| Conductor Material | Tinned Copper | |
| Jacket Color | Black | |
| Cable Diameter Max (in) | 0.17 | |
| Stranding | 104 | |
| Insulation Material | LSZH, RHH TelcoHyde 5221, 105°C Dry, 60°C Wet | |
| Voltage Rating | 600V | |
| Bend Radius (in) | 2 | |
| Cable Weight per Foot | 0.02 |
Please refer to the following attachments for additional details on the product.
