Manufacturer
Cisco
MPN
ONS-XC-10G-S1
Available
121
Condition
Refurbished
(refurbished) Dwdm Mod Xfp Oc192/stm64
The Cisco ONS-XC-10G-S1 is a high-performance Dwdm Mod Xfp Oc192/stm64 module designed for use in Cisco optical networking solutions. With a data transfer rate of 10 Gbps, the ONS-XC-10G-S1 is capable of handling high-bandwidth applications and services, such as video streaming, cloud computing, and data center connectivity.
It supports both OC192 and STM64 protocols, making it suitable for a variety of network architectures. This module utilizes XFP (10 Gigabit Small Form Factor Pluggable) technology, which allows for easy installation and removal without disrupting network operations.
Specifications | |
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 6.8 dB |
| Maximum Distance: | 10km |
| Supported Data Rate: | 1.24-11.32Gbps |
| Supported Applications: | 10G Ethernet (10.31Gbps), Gigabit Ethernet (1.25 Gbps), 10G Fiber Channel (10.52 Gbps), 8G Fiber Channel (8.5 Gbps), 4G Fiber Channel (4.25 Gbps), 2G Fiber Channel (2.125 Gbps), 1G Fiber Channel (1.0625 Gbps), STM-16 (2.488 Gbps), STM-64 (9.95Gbps), ODU0 (1.244Gbps), ODU1 (2.498Gbps), ODU2 (10.037Gbps), ODU2e (10.399Gbps), OTU1 (2.66Gbps), OTU2 (10.70Gbps), OTU1f (11.27Gbps), OTU2f (11.32Gbps), OTU1e (11.049Gbps), OTU2e (11.095Gps) |
| DDM/DOM: | Support |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -8.2 dB |
| Maximum Transmitting Power: | 1 dB |
| Receiver Sensitivity: | -15 dBm |
| Receiver Overload: | 0.5 dBm |
| Dispersion: | 70-100 ps/nm |
| Transmitter Type: | DFB Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Compliance: | CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8077i XFP MSA Rev.4.5, RoHS |
| Transceiver Type: | XFP |
