Manufacturer
Ciena
MPN
XCVR-A00Z85
Available
37
Condition
New
Sfp 10g Mmf 300m Hardened
The Ciena XCVR-A00Z85 is a high-performance SFP (Small Form-factor Pluggable) transceiver designed for use in 10 Gigabit Ethernet networks. This transceiver is specifically designed for use with multi-mode fiber (MMF) cables and has a maximum transmission distance of 300 meters.
It is compatible with a wide range of Ciena networking equipment, ensuring seamless integration into your existing network infrastructure. With a data transfer rate of 10 Gbps, the XCVR-A00Z85 is ideal for high-bandwidth applications such as data centers, enterprise networks, and service provider networks.
It supports a variety of protocols, including Ethernet, Fibre Channel, and SONET/SDH, making it a versatile and reliable choice for your network needs.
Specifications | |
| Media Type: | Multi-Mode Fiber (MMF) |
| TX Wavelength: | 850 nm. |
| RX Wavelength: | 850 nm. |
| Minimum Optical Budget: | 4.6 dB |
| Maximum Distance: | 300m |
| Supported Data Rate: | 1.24-11.32Gbps |
| Supported Applications: | 10G Ethernet (10.31Gbps), Gigabit Ethernet (1.25 Gbps), 10G Fiber Channel (10.52 Gbps), 8G Fiber Channel (8.5 Gbps), 4G Fiber Channel (4.25 Gbps), 2G Fiber Channel (2.125 Gbps), 1G Fiber Channel (1.0625 Gbps), STM-16 (2.488 Gbps), STM-64 (9.95Gbps), ODU0 (1.244Gbps) |
| DDM/DOM: | Support |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 20 nm (840-860 nm) |
| Rx Wavelength Bandwidth: | 20 nm (840-860 nm) |
| Minimum Transmitting Power: | -6.5 dB |
| Maximum Transmitting Power: | 1 dB |
| Receiver Sensitivity: | -11.1 dBm |
| Receiver Overload: | -1 dBm |
| Dispersion: | 110 ps/nm |
| Transmitter Type: | VSCEL Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Compliance: | CE, Class 1 FDA and IEC60825-1 Laser Safety Compliant, INF-8077i XFP MSA Rev.4.5, RoHS |
| Transceiver Type: | XFP |
