Manufacturer
ADRF
MPN
SDR-33-BT
Available
18
Condition
New
ADRF SDR-33-BT - 2.5ghz Repeater Module, 96db Gain, 33dbm Output
This repeater module offers an impressive 96db gain, allowing for extended coverage and improved signal strength in areas with weak or spotty reception. The SDR-33-BT is equipped with advanced Bluetooth technology, allowing for easy remote monitoring and control of the repeater module.
This feature makes it convenient for technicians to adjust settings and troubleshoot any issues without having to physically access the device. This repeater module is compact and easy to install, making it a cost-effective solution for improving wireless coverage in any environment.
Downlink/Uplink Frequencies: 2496 – 2562 MHz, 2502 – 2568 MHz, 2618 – 2684 MHz, 2624 – 2690 MHz
Digitally filtered with sharp roll-off (>50 dBc @ +1 MHz from sub-band edge)
95 dB of max gain
33 dBm max output power
Specifications | |
| Type | Singleband |
| Band | IMT-E 2600 |
| Uplink | 2496 to 2562 MHz, 2502 to 2568 MHz, 2618 to 2684 MHz, 2624 to 2690 MHz |
| Downlink | 2496 to 2562 MHz, 2502 to 2568 MHz, 2618 to 2684 MHz, 2624 to 2690 MHz |
| Output Power | 33 dBm |
| Power Consumption | 150 / 180 / 200 W |
| Humidity | 5 - 90%, non condensing |
| Gain | 95 dB |
| Gain Control | 40 dB |
| IP Rating | IP20 |
| Noise Figure | 5 dB |
| AC Supply Voltage | 110 to 130 Vac, 60 Hz (Default) or 210 to 240 Vac, 60 Hz (Selectable Switch |
| Indoor/Outdoor | Indoor |
| VSWR | 1.50:1 |
| Delay | 5 us |
| Standard Supported | LTE |
| Operating Temperature | 14 to 122 Degree F |
| Weight | 26 lbs |
| Dimension | 19.0 x 14.0 x 19.1 Inches |
| Connector | N Type, N Type - Female |
