Manufacturer
Juniper Networks
MPN
740-031850
MOQ
6
Available
418
Condition
Refurbished
Juniper Networks 740-031850 - (refurbished) Juniper-sumitomo Sfp-1ge-lx, Ipuia9emab, Single Port 1000bas
The Juniper Networks 740-031850 is a refurbished single port 1000BASE-LX SFP (Small Form-factor Pluggable) module designed for use with Juniper and Sumitomo networking equipment. This module, with the part number IPUIA9EMAB, is a high-quality, cost-effective solution for expanding your network's connectivity options.
It supports data transfer speeds of up to 1 Gbps, making it ideal for high-speed data transmission and network applications. With its small form-factor design, the Juniper Networks 740-031850 is easy to install and can be hot-swapped without disrupting your network's operation.
Key Technical Data | |
|---|---|
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 13 dB |
| Maximum Distance: | 10km |
| Supported Data Rate: | 1.063-1.25Gbps |
| Supported Applications: | Gigabit Ethernet (1.25 Gbps), 1G Fiber Channel (1.0625 Gbps) |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -9 dB |
| Maximum Transmitting Power: | -3 dB |
| Receiver Sensitivity: | -22 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 70-100 ps/nm |
| Transmitter Type: | FP Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Transceiver Type: | SFP |
