Manufacturer
Ciena
MPN
XCVR-040M31
MOQ
3
Available
238
Condition
New
Ciena XCVR-040M31 - Optical Connector 1 Gig Sm Sfp Optic Lc Con
The Ciena XCVR-040M31 is a high-quality optical connector designed for 1 Gigabit Ethernet connections. It is compatible with Ciena networking equipment and is specifically designed for use with single-mode fiber optic cables. This small form-factor pluggable (SFP) optic features an LC connector, making it easy to install and connect to your network.
It supports a maximum data transfer rate of 1 Gbps and has a reach of up to 10 kilometers. This makes it ideal for long-distance connections in a variety of networking environments. This Ciena optic is also hot-swappable, meaning it can be inserted or removed from a network device without disrupting the overall network operation. It also supports digital diagnostics monitoring (DDM), allowing for real-time monitoring of the optic's performance and health.
Key Technical Data | |
|---|---|
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 17 dB |
| Maximum Distance: | 40km |
| Supported Data Rate: | 1.063-1.25Gbps |
| Supported Applications: | Gigabit Ethernet (1.25 Gbps), 1G Fiber Channel (1.0625 Gbps) |
| Temperature Range: | Standard 0°-70°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -6 dB |
| Maximum Transmitting Power: | 0 dB |
| Receiver Sensitivity: | -23 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 300-400 ps/nm |
| Transmitter Type: | DFB Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Transceiver Type: | SFP |
