Manufacturer
TE Connectivity
MPN
TRAB9023NP
MOQ
2
Available
0
Condition
New
TE Connectivity TRAB9023NP - 902-928 Phantom Ant,No Grnd,Black,NF
The TE Connectivity TRAB9023NP is a high-performance antenna designed for use in the 902-928 MHz frequency range. This antenna features a unique Phantom design, which eliminates the need for a ground plane, making it ideal for use in applications where a traditional antenna may not be suitable. The antenna is also designed with a sleek black finish and features a narrow frequency bandwidth, making it perfect for use in narrowband applications.
Specifications | |
| RF Family/Standard | Cellular |
| Frequency Group | UHF (300MHz ~ 1GHz) |
| Frequency (Center/Band) | 915MHz |
| Frequency Range | 902MHz ~ 928MHz |
| Antenna Type | Dome |
| Number of Bands | 1 |
| VSWR | 2 |
| Gain | 3dBi |
| Power - Max | 100 W |
| Termination | N Type Female |
| Mounting Type | Panel Mount |
| Height (Max) | 2.700" (68.58mm) |
| Applications | GSM |
Please refer to the following attachments for additional details on the product.
No specifications available.
