2-units min. TE Connectivity 2.4-2.5ghz 3db Blk Phantom Ant - TRAB24003P
Slide 1 of 1
Free shipping included.
Manufacturer
TE Connectivity
MPN
TRAB24003P
MOQ
2
Available
19
Condition
New
2.4-2.5ghz 3db Blk Phantom Ant
Specifications
| Product Attribute | Attribute Value |
|---|---|
| Product Category: | Antennas |
| RoHS: | Details |
| Product Type: | 2.4GHz Antenna - 2.4GHz, 5GHz, Bluetooth, WiFi, WLAN, Zigbee |
| Product: | Outdoor Antennas |
| Type: | Passive Antenna |
| Minimum Frequency: | 2.4 GHz |
| Maximum Frequency: | 2.5 GHz |
| Protocol - Bluetooth, BLE - 802.15.1: | Bluetooth |
| Protocol - WiFi - 802.11: | 802.11, WLAN |
| Protocol - ANT, Thread, Zigbee - 802.15.4: | 802.15.4 (ANT, Thread, Zigbee), 802.16 |
| Mechanical Style: | Whip |
| Style: | Stubby |
| Gain: | 3 dB |
| Impedance: | 50 Ohms |
| VSWR: | 2.1 |
| Power Rating: | 100 W |
| Number of Bands: | 1 Band |
| Mounting Style: | Direct / Permanent Mount |
| Termination Style: | Connector |
| Antenna Connector Type: | N Female |
| Centre Frequency: | 2.45 GHz |
| Application: | Wireless Applications |
| Length: | 2.75 in |
| Cable Type: | - |
| Diameter: | 1.438 in |
| Subcategory: | Antennas |
| Unit Weight: | 78,470 g |
Please refer to the following attachments for additional details on the product.
No specifications available.
