Manufacturer
Ciena
MPN
XCVR-020M31
MOQ
2
Available
413
Condition
New
Ciena XCVR-020M31 - Optical Card 1 Gig Sm Sfp Optic Lc Connector
The Ciena XCVR-020M31 is an optical card designed for high-speed data transmission over fiber optic networks. It is a 1 Gigabit small form-factor pluggable (SFP) optic with an LC connector, making it compatible with a wide range of networking equipment.
The small form-factor pluggable design of this optic allows for easy installation and replacement, without the need for specialized tools or equipment. The LC connector ensures a secure and stable connection, minimizing the risk of signal loss or interruption.
Key Technical Data | |
|---|---|
| Media Type: | Single-Mode Fiber (SMF) |
| TX Wavelength: | 1310 nm. |
| RX Wavelength: | 1310 nm. |
| Minimum Optical Budget: | 13 dB |
| Maximum Distance: | 20km |
| Supported Data Rate: | 1.063-1.25Gbps |
| Supported Applications: | Gigabit Ethernet (1.25 Gbps), 1G Fiber Channel (1.0625 Gbps) |
| Temperature Range: | Industrial -45°C – +85°C |
| Connectors: | Double LC |
| Tx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Rx Wavelength Bandwidth: | 100 nm (1260-1360 nm) |
| Minimum Transmitting Power: | -9 dB |
| Maximum Transmitting Power: | -3 dB |
| Receiver Sensitivity: | -22 dBm |
| Receiver Overload: | -3 dBm |
| Dispersion: | 140-160 ps/nm |
| Transmitter Type: | FP Laser |
| Receiver Type: | PIN photodiode |
| Power: | +3.3V single power supply |
| Chipset: | MAXIM, MINDSPEED, SEMTECH |
| Transceiver Type: | SFP |
